Name: Polcd 240x320 MCU SPI RGB Interface Lcd Screen ST7789V 2.8 Inch Tft Lcd Display Module
Brand: Shenzhen P&O Technology Co., Ltd
SKU: P028B126-IPS
Availability: InStock

Haus > produits > tft lcd-Modul >

Polcd 240x320 MCU SPI RGB Interface Lcd Screen ST7789V 2.8 Inch Tft Lcd Display Module

2.8 inch TFT LCD display module

ST7789V SPI RGB LCD screen

MCU interface TFT LCD module

Herkunftsort:

Shenzhen, China

Markenname:

Polcd

Zertifizierung:

RoHS, ISO9001

Modellnummer:

P028B126-IPS

Treten Sie mit uns in Verbindung

Fordern Sie ein Zitat

Produkt-Details

Auflösung:

240x320

Schnittstelle:

MCU 8bit

Treiber IC:

ST7789V

Helligkeit (CD/m²):

Nisse 300

Blickwinkel:

IPS-Blickwinkel

Anzeigebereich:

43.20 (h) x57.60 (v) mm

Zahlungs-u. Verschiffen-Ausdrücke

Min Bestellmenge

1 Stück

Preis

Please contact us for latest price

Verpackung Informationen

FCL-Größe: 40*30*20cm/Probe Verpacken: 20*18*13cm

Lieferzeit

1-7 Arbeitstage

Zahlungsbedingungen

T/T, L/C, Kreditkarte, Paypal, D/A, D/P, Western Union, MoneyGram

Versorgungsmaterial-Fähigkeit

25.000 PCS pro Tag

Verwandte Produkte

Video

Polcd 240x320 MCU SPI RGB Interface Lcd Screen ST7789V 2.8 Inch Tft Lcd Display Module

Erhalten Sie besten Preis

Video

Polcd 2.8'' 2.8 Inch 240x320 Resolution MCU SPI RGB Interface IPS TFT LCD Display With ST7789V Driver IC

Erhalten Sie besten Preis

Video

Polcd 3,5 Zoll IPS TFT LCD 320*480 Ili9488 Antrieb Ic 600:1 Kontrastverhältnis

Erhalten Sie besten Preis

Video

Polcd mit hoher Leuchtkraft 3,5 Zoll kleines TFT-LCD-Display 30pins 320*480 Kapazitiver Touchscreen

Erhalten Sie besten Preis

Treten Sie mit uns in Verbindung

00-86-13714394335

anna@polcd.com

86-755-21011746

Kontakt jetzt

Produkt-Beschreibung

Parameter:

Item	Specification
Model	P028B126-IPS
Screen Size	2.8 inch
Number of Pixel	240RGB(H)x320(V)
Display area	43.20(H)x57.60(V)
Pixel pitch	0.180(H)x0.180(V)mm
Pins	24 pins
Outline Dimension	50.00x69.20x2.30mm
Pixel arrangement	RGB Vertical Stripe
Display mode	Normally Black
Viewing Direction(eye)	ALL
Gray inversion direction	--
Display Color	262K
Luminance(cd/m2)	300 nit
Contrast Ratio	1200:1
Surface treatment	--
Interface	MCU 8bit
Back-light	LED Side-light type
Drive IC	ST7789V
Operation Temperature	-20~70℃
Storage Temperature	-30~80℃

There are several medical devices that use 2.8 inch TFT LCDs with RTP, including:

Handheld Patient Monitors: These devices are used for monitoring vital signs such as blood pressure, heart rate, and oxygen saturation. A 2.8 inch TFT LCD with RTP can provide a clear display of the patient's vital signs, and the touch panel can be used to input data and adjust settings.

Portable Ultrasound Machines: These devices are used for imaging internal organs and tissues. A 2.8 inch TFT LCD with RTP can provide a clear display of the ultrasound image, and the touch panel can be used to adjust settings and perform measurements.

Portable ECG Monitors: These devices are used for recording and analyzing the electrical activity of the heart. A 2.8 inch TFT LCD with RTP can display the ECG waveform and allow the user to input patient information and adjust settings.

Handheld Pulse Oximeters: These devices are used for measuring the oxygen saturation of the blood. A 2.8 inch TFT LCD with RTP can display the oxygen saturation level and pulse rate, and the touch panel can be used to input patient information and adjust settings.

Portable Blood Glucose Meters: These devices are used for measuring blood glucose levels in diabetic patients. A 2.8 inch TFT LCD with RTP can display the glucose level and allow the user to input patient information and adjust settings.
