Name: Polcd 2.1 Inch 480x480 IPS Circular TFT Color Display LCD Module LCM Panel
Brand: Shenzhen P&O Technology Co., Ltd
SKU: P021B002-IPS
Availability: InStock

Haus > produits > Kundenspezifische TFT-Anzeigen >

Polcd 2.1 Inch 480x480 IPS Circular TFT Color Display LCD Module LCM Panel

Herkunftsort:

Shenzhen, China

Markenname:

Polcd

Zertifizierung:

RoHS, ISO9001

Modellnummer:

P021B002-IPS

Treten Sie mit uns in Verbindung

Fordern Sie ein Zitat

Produkt-Details

Auflösung:

2.1 Zoll 480x480

Schnittstelle:

3Line SPI 18bit RGB

Treiber IC:

ST7701s

Helligkeit (CD/m²):

Nisse 300

Blickwinkel:

IPS-Blickwinkel

Anzeigebereich:

53.28 ((H) x53.28 ((V) mm

Zahlungs-u. Verschiffen-Ausdrücke

Min Bestellmenge

1 Stück

Preis

Please contact us for latest price

Verpackung Informationen

FCL-Größe: 40*30*20cm/Probe Verpacken: 20*18*13cm

Lieferzeit

1-7 Arbeitstage

Zahlungsbedingungen

T/T, L/C, Kreditkarte, Paypal, D/A, D/P, Western Union, MoneyGram

Versorgungsmaterial-Fähigkeit

40.000 PCs pro Tag

Verwandte Produkte

Video

Polcd Custom 2.1 Inch IPS TFT Round LCD Display Module with SPI RGB Interface

Erhalten Sie besten Preis

Video

Polcd 1,69 Zoll Touchscreen LCD-Display 240x280 SPI-Schnittstelle Kleines TFT-Modul

Erhalten Sie besten Preis

Video

Polcd 4 Zoll Rundes Kreisförmiges TFT-Display 720x720 MIPI-Schnittstelle 30 Pins ST7703 TFT-LCD-Bildschirmmodul

Erhalten Sie besten Preis

Video

Polcd 3,5' 3,5 Zoll SPI-Schnittstelle 320x480 Auflösung ST7796U Treiber IC IPS TFT LCD-Display Modul

Erhalten Sie besten Preis

Treten Sie mit uns in Verbindung

00-86-13714394335

anna@polcd.com

86-755-21011746

Kontakt jetzt

Produkt-Beschreibung

Introduction:

The 2.1-inch circular LCD (Liquid Crystal Display) is an innovative and compact display module that offers a versatile solution for various electronic applications. With its small form factor and excellent visual performance, this circular LCD is becoming increasingly popular in today's technology-driven world.

Parameter:

Model	P021B002-IPS
Screen Size	2.1 inch
Number of Pixel	480RGB(H)x480(V)
Display area	53.28(H)x53.28(V)mm
Pixel pitch	111(H)x111(V)um
Pin	40 pins
Outline Dimension	56.18x59.71x2.2mm
Pixel arrangement	RGB Vertical Stripe
Display mode	Normally Black
Viewing Direction(eye)	ALL
Display Color	262k
Luminance(cd/m²)	300 nit
Contrast Ratio	1000:1
Interface	3Line SPI 18bit RGB
Back-light	LED Side-light type
Drive IC	ST7701S
Operation Temperature	-20~70℃
Storage Temperature	-30~80℃

Features:

1. Compact Design: Making it ideal for devices with limited space or those that require a small display area. Its circular shape adds a unique aesthetic appeal to the overall design.

2. High Resolution: Despite its small size, this LCD module delivers impressive image quality with high resolution. The display offers sharp and vibrant visuals, ensuring an enhanced user experience.

3. IPS Wide Viewing Angle: The circular LCD incorporates advanced viewing angle technology, enabling users to view the screen from various angles without compromising image clarity. This feature is particularly beneficial for devices that require multiple users to view the screen simultaneously.

4. Energy Efficiency: The designed to be energy-efficient, consuming minimal power while delivering optimal performance. This feature is crucial for portable devices and those with limited power resources, contributing to extended battery life.

Polcd 2.1 Inch 480x480 IPS Circular TFT Color Display LCD Module LCM Panel 0
